Zebra ZM400 Barcode Printer

Standard Features * Thermal transfer and direct thermal operating modes ( can only use one mode at a time) * Die-cast aluminum base, frame, and printhead mechanism * Metal media cover with large clear window * 16 MB DRAM, 8MB Flash * 203dpi ( 8 dots/ mm) printhead * RS-232C Serial Interface * High Speed, IEEE 1284, Bi-Directional Parallel Interface * USB 2.0 * Transmissive and reflective media sensors * Multi-lingual backlit 240x128 pixel graphic display * Color-coded operator cues * RFID Ready * 7 bitmapped and 1 scalable font ( CG Triumvarate Bold Condensed) * 32-bit processor * Auto-calibration * Auto detectable ( 90V - 265V) power supply * Element Energy Equalizer™ ( E3® ) ( for print head energy control) * Real Time Clock * Unicode™ - Compliant * Quick change printhead and platen * Charcoal gray form design ( for improved smudge resistance) * ZPL® or ZPLII® ( Zebra Programming Language® ) Printer Specifications Resolution 203 dpi ( 8 dots/ mm) 300 dpi ( 12 dots/ mm) 600 dpi ( 23.5 dots/ mm) Memory * 16 MB DRAM * 8 MB Flash * 64 MB Factory-Installed On-Board Optional Flash ( optional) Print width 4.09" ( 104 mm) Print length * Length with 203 dpi: 157" ( 3, 988 mm) * Length with 300 dpi: 73" ( 1, 854mm) * Length with 600 dpi: 39" ( 991mm) Print speed 203 dpi 10" ( 254 mm) / sec 300 dpi 8" ( 203 mm) / sec 600dpi 4" ( 102 mm) / sec Media sensors Reflective Transmissive Media Characteristics Maximum label and liner width * 4.5" ( 114 mm) - tear & cutter * 4.25" ( 108mm) - peel & rewind Minimum label and liner width 1" ( 25 mm) - tear & cutter, peel & rewind Maximum label and liner length 39" ( 991mm) Maximum roll diameter 8" ( 203 mm) Core diameter 3" ( 76 mm) Media thickness 0.0023" ( .058 mm) to 0.010" ( 0.25 mm) Media types black mark, continuous, die-cut, fanfold, notched, perforated, tag stock Ribbon Characteristics Outside diameter 3.2" ( 81.3 mm) Standard length 1476' ( 450 m) or 984' ( 300 m) Ratio 3: 1 media roll to ribbon ratio Ribbon width 2" ( 51 mm) to 4.33" ( 110 mm) Ribbon setup Ribbon wound ink-side out or ribbon wound ink-side in ( configurable one or the other, but not both) ID Core 1.0" ( 25.4 mm) Operating Characteristics Operating temperature TT: Operating temperature 40° F ( 5° C) to 104° F ( 40° C) Thermal transfer DT: Operating temperature 32° F ( 0° C) to 104° F ( 40° C) Direct thermal Storage temperatures -40° F ( -40° C) to 140° F ( 60° C) Operating humidity 20-85% non-condensing R.H. Storage humidity 5-85% non-condensing R.H. Electrical Universal auto-detectable ( PFC-compliant) power supply 90-265 VAC Agency approvals * IEC 60950-1 EN 55022 Class B * EN 55024 * EN 61000-3-2 * EN 61000-3-3 Physical Characteristics Width 10.9" ( 278 mm) Height 13.3" ( 338 mm) Depth 18.7" ( 475 mm) Weight 32.4 lbs ( 15 kg) Shipping weight 49 lbs ( 22 kg) Related Products Options * 300 dpi ( 12 dots/ mm) printhead * 600 dpi ( 23.5 dots/ mm) printhead * 64 MB Factory-Installed, On-Board Flash Memory ( 58 MB user available) * Cutter with catch tray * Value peel ( front mount, passive peel option with no liner take-up) * Peel with liner take-up * Rewind, internally rewinds full label roll on three-inch core ( comes with taller, non-standard printer base) * Ribbon supply spindle for ribbon ink coated inside * RFID Field Upgrade Kit * ZebraDesigner * ZebraDesigner Pro * ZebraDesigner for XML * ZebraNet Bridge Enterprise * XML-enabled printing * Printhead conversion kits * ZebraCare Extended Warranty * European and Asian font sets * APL-I * APL-D Communication and Interface Capabilities * RS-232C serial port * RS 232 to RS-422/ 485 serial port adaptor * RS232 DB9 to DB25 adaptor * High speed, IEEE 1284, bi-directional parallel interface * ZebraNet Wireless Plus ( optional) * ZebraNet 10/ 100 Print Server ( internal/ external option) * ZebraNet PrintServer II ( external option only) Programming Languages Core programming languages ZPL, ZPL II, EPL, XML Bar Codes/ Symbologies Linear Codabar Code 11 Code 128 with subsets A/ B/ C and UCC case codes Code 39 Code 93 EAN-13 EAN-8 Industrial 2-of-5 Interleaved 2-of-5 Logmars MSI Planet Code Plessey Postnet RSS ( reduced space symbology) Standard 2-of-5 UPC and EAN 2 or 5 digit extensions UPC-A UPC-E 2-dimensional Aztec Codablock Code 49 Data Matrix MaxiCode QR Code PDF417 MicroPDF417 RSS / GS1 DataBar family ( 12 barcodes) Fonts and Graphics * Standard fonts: 7 bitmapped, 1 smooth scalable ( CG Triumvirate Bold Condensed) * Sets: IBM Code Page 850 International character set * Optional European and Asian font sets * Supports user-defined fonts and graphics, including custom logos * ZPL II drawing commands, including boxes and lines
